Cyclone Feed Heavy Duty Slurry Pump Metal Lined RAL5015 with Red Prime Oxider for Minining Industries
Introduction:
The slurry pump is installed with 5-vane closed type metal impellers. The standard Part Number is F6147. The material of the impellers can be High chrome A05, Ultra chome A49, and Natural rubber , and Polyurethane U01.
Our slurry pumps are heavy duty, single stage, single suction centrifugal pump designed for applications like mining and processing, mining and metallurgical plants, power plants, cement production enterprises, and diamond-gold mines, technological crushing line, mineral processing, etc.
This is a heavy duty slurry pump that is extremely durable and easy to maintain. It is highly efficient and corrosion and erosion resistant.
It has a long wear life and is extremely cost efficient. The use of effective liners make this pump easy to maintain.
The pump’s many benefits include the bearing assembly, cover/frame plates, suction cover, liners, the impeller, and it has a one piece base.
SH-150E(8/6E-) is a slurry pump with discharge size 6 inch, and it is almost the best popular pump at SME.
8/6E- is mostly sold to our customers from Russia, Holland, Italy and other Eastern and Western European countries. SME will always be your reliable partner for quality slurry pumps and pump spare parts.
These pumps are characterized by long life, efficient operation and easy maintenance with its low cost.
Pumps are available with either a rubber or a metal lining of abrasive - and corrosion resistant materials. Used bearings for heavy duty, with the increased load on them.
Specifications:
| Model | SH/150E |
| Oulet | 6-inch |
| Capacity | 360-828m3/h |
| TDH | 10-61m |
| Rated Motor Power | 120Kw |
| Speed | 500-1140r/min |
| NPSH | 2-9m |
Our Factory:
Standard Material of Wet-end Parts: Hi-Chrome Alloy A05
| Designation | Description | C | Mn | Si | Ni | Cr | Mo | P | S | V | Hardness |
| A05 | 27% Cr White Iron | 2.92 | 0.98 | 0.54 | 0.8 | 26-28 | ≤0.8 | 0.062 | 0.05 | 0 | 58-62HRC
|
Typical Applications:
Ash Handling
Cyclone Feeds
Pulp and Paper
Abrasive Slurries
Coal Preparation
Mineral Processing
Aggregate Processing
Wet-end Spare Parts List:
| Parts | Impeller | Volute Liner | Throatbush | Frame Plate Liner Insert | Expeller (Ring) |
| Material | A05 | A05 | A05 | A05-High Chrome Alloy | White Iron |
